Column Tension And Compression Load Cell T304
Small, dynamic, and available out of the box. The T304 tension and compression sensor is suitable for any space, suitable for measuring tension and compression forces, and is very cost-effective.
Product Description
Specifications
| Specifications | Technique |
| Nominal(rated)torque Mnom | 0.5,1,1.5,2,3,5kN |
| Nominal(rated)sensitivity | 1.5±20%mV/V |
| Zero balance | ±0.05mV/V |
| Non-linearity | 0.20%F.S. |
| Hysteresis | 0.10%F.S. |
| Repeatability | 0.10%F.S. |
| Creep(30min) | 0.10%F.S. |
| Temp.effect on sensitvty | 0.05%F.S./10℃ |
| Temp.effect on zero | 0.05%F.S./10℃ |
| Nput impedance | 780±20Ω |
| Output impedance | 700±10Ω |
| Insulation | ≥5000MΩ/100VDC |
| Recommended excitation | 5-15V |
| Maximum excitation | 15V |
| Compensated temp range | -10-60℃ |
| Operating temperature range | -20-80℃ |
| Safe load limit | 150%F.S |
| Ultimate overload | 200%F.S. |
| lP class | IP66 |
| Cable size | φ4×4000mm |
| Material | Stainless Steel |
FAQ
What are your terms of delivery?
EXW, FOB, CFR, CIF.
How about your delivery time?
Generally, it will take 10 to 15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Can you produce according to the samples?
Yes, we can produce by your samples or technical drawings.
What is your sample policy?
We can supply the sample if we have ready parts in stock.
Do you test all your goods before delivery?
Yes, we have 100% test before delivery.
How do you make our business long-term and good relationship?
We keep excellent quality, thoughtful after-sales service and competitive price to ensure our customers' benefit;
We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
